Powershield Centurion 1000VA UPS
PowerShield PSCE1000 Centurion Tower, 1000VA / 900W Online Double Conversion UPS, 396mm x 145mm x 240mm, 2 Year Advanced Replacement Warranty
FREQUENCY CONVERSION MODEL - The PowerShield Centurion is designed to electrically protect, servers, communication, industrial, medical and other mission critical equipment.
The PowerShield Centurion is a True On-Line Double Conversion UPS designed to guarantee trouble free operation of protected equipment in harsh electrical environments. Versatile management and hardware options offer the flexibility to build up a power protection solution to fit any application. The PowerShield Centurion range includes programmable outlets so less important loads can automatically shed sometime during battery backup.
The PowerShield Centurion is a True On-Line Double Conversion UPS designed to guarantee trouble free operation of protected equipment in harsh electrical environments. Versatile management and hardware options offer the flexibility to build up a power protection solution to fit any application. The PowerShield Centurion range includes programmable outlets so less important loads can automatically shed sometime during battery backup.
PSCE1000
RRP $1,364.00
Available in stock
Product Information
-
- 1000VA / 800 Watts
- True On-Line Double Conversion
- Wide input voltage range (110-300 VAC)
- Input power factor correction 0.98
- 50Hz/ 60Hz frequency converter mode
- Programmable power outlets
- Emergency power off function (EPO)
- Eco-mode operation for energy efficiency
- Generator compatible
- Extended battery backup times with daisy chained battery modules
- Communication: USB, RS232
- Optional SNMP and AS400 dry relays available
- Optional EMBS - External Maintenance Bypass Switch available for all models
- N + X parallel redundancy available for 6kVA & 10kVA models
- Monitoring and Shutdown Software included
- For Technical Help please contact PowerShield on 1300 305 393
Specifications
| Warranty | 2 Years |
| Active Cooling | No |
| Audible Alarm | Batt. Mode low battery overload fault etc. |
| Australian Outlets - Surge Protection | Single Phase |
| Australian Outlets - UPS | 2 |
| Battery Type | 12V 9AH (x3) |
| Capacity VA | 900W/1000VA |
| Dimensions | 396mm x 145mm x 240mm |
| Expandable Batteries | Yes |
| Form factor | Tower |
| Frequency Range | 40/70Hz |
| Hard-Line | No |
| Hot Swappable Batteries | No |
| IEC 13 Count | 2 |
| IEC 19 Count | 0 |
| Interface | USB and RS232 as standard. Intelligent slot for PSSNMPV4 or PSAS400 dry contact or PSMBUS |
| LCD Alarm | UPS Status Load Level Battery Level Input/Output Voltage Battery Time Remaining and Fault Indica |
| Model Number | PSCE1000 |
| Noise Level | Less than 50dBA @ 1metre |
| Operating Temperature Range | 0-40 C |
| Output Voltage | 200-240Vac |
| Phase Count | Single Phase |
| Sine Wave | Pure Sinewave |
| SNMP Compatible | Yes |
| Software | Power Shield Netguard |
| Surge Protection | 1248 Joules / 39000Amps |
| Topology | True online double-conversion |
| Voltage | 200-240Vac |
| Voltage Range | 160-300Vac |
| Weight | 12.5kg |
